Magnetic switch in distribution box

Optical access and telecom site reference Published 16 Nov 2024

Use this reference to prepare product questions for CGWEB NETWORKS. Check interfaces, capacity, protection and installation requirements against the current product documentation.

A magnetic switch distribution box is a device that centralizes power or signal distribution while allowing on/off control via a magnetic switch.

Overview

A magnetic switch distribution box combines the functionality of a standard distribution box with a magnetically actuated switch to control power or signal flow. The magnetic switch allows the box to be turned on or off without direct electrical contact, enhancing safety and convenience. These boxes are used in applications ranging from industrial automation to radio-controlled systems and modular electrical installations.

Industrial and Automation Applications

In industrial settings, distribution boxes provide decentralized power and signal distribution for automation systems. They can house multiple components such as solenoids, sensors, and I/O modules. Magnetic switches in these boxes allow operators to activate or deactivate the system safely without opening the enclosure, which is particularly useful in harsh environments or where moisture and dust are present.

For example, the SCHUNK EGM-JB distributor box enables centralized connection of multiple solenoids to a controller using a magnetic interface, reducing wiring complexity and installation time.

RC and Battery-

Powered Systems

In radio-controlled (RC) applications, magnetic switch distribution boxes manage battery power and signal redundancy. The Jeti Central Box 210, for instance, uses a magnetic switch to turn the unit on or off. The switch is activated by holding a supplied magnet near the target slot, allowing wireless and contactless control.

This system supports multiple batteries, telemetry, and fail-safe functions, ensuring reliable power distribution and signal management for servos and receivers.

Key Features

Centralized or decentralized distribution of power and signals Magnetic on/off control for safety and convenience Compatibility with multiple devices such as solenoids, sensors, or RC servos Redundancy and fail-safe options in critical applications Pluggable and modular design for flexible installation BenefitsReduces wiring complexity and installation timeEnhances safety by allowing contactless switchingSupports modular and scalable system designProvides reliable operation in harsh or moisture-prone environmentsMagnetic switch distribution boxes are therefore versatile solutions for both industrial automation and specialized applications like RC systems, combining efficient power distribution with safe, contactless control.
