Mexican Waterproof Distribution Box Dimensions

Mexican waterproof distribution boxes typically range from small 4-module enclosures to large 54-module units, with IP65 protection and multiple layer options.

Common Dimensions and Configurations

Module Capacity: Boxes are available in 4, 6, 8, 12, 18, 24, 36, and 54 modules, accommodating different electrical setups. Some industrial models offer 3 to 48 modules. Layers: Options include single, double, or triple layers, allowing for flexible internal wiring and separation of circuits.

Material: Most boxes are made of ABS or polycarbonate, providing UV resistance and durability for outdoor use. Protection Level: Standard IP65, with some models rated up to IP66, ensuring dustproof and waterproof performance. Mounting: Surface-mounted designs are common, with DIN rail compatibility (TH35x7.

5) for modular components. Dimensions: While exact measurements vary by module count and manufacturer, typical small boxes (4–12 modules) measure approximately 200–400 mm in height, 150–300 mm in width, and 80–150 mm in depth, whereas larger boxes (24–54 modules) can reach 600–1000 mm in height, 400–600 mm in width, and 150–250 mm in depth. Custom sizes are often available for specific installations.

Additional Features

Transparent Windows: Many boxes include a PC tinted window for monitoring without opening the enclosure.

U

V and Heat Resistance: Designed for outdoor use, withstanding high temperatures and UV exposure. Customizable Knockouts: Holes can be opened according to installation requirements for cable entry. Compliance: Meets IEC standards for electrical protection and safety.

These specifications make Mexican waterproof distribution boxes suitable for industrial, commercial, photovoltaic, and residential applications, providing reliable protection for electrical equipment in harsh environments.
